Hamm HD 14i TT
Find Out More
-
Simple transport, simple loading
-
Excellent view of tires, machine and construction site
-
Compact dimensions
-
Simple, intuitive and language-neutral control
-
Ergonomic driver platform
| DIESEL ENGINE - Exhaust gas after-treatment: | DOC-DPF |
|---|---|
| DIESEL ENGINE - Power ISO 14396, rpm: | 2,700 rpm |
| TIRE DIMENSIONS - Width over tires, front: | 44.4 in |
| WEIGHTS - Operating weight with cab: | 8,478 lbs |
| MACHINE DIMENSIONS - Total height with ROPS: | 102 in |
| TIRE DIMENSIONS - Number of tires, front: | 3 |
| DIESEL ENGINE - Manufacturer: | KUBOTA |
| DIESEL ENGINE - Power ISO 14396, kW: | 36.8 kW |
| DIESEL ENGINE - Cylinders, quantity: | 4 |
| WEIGHTS - Operating weight with ROPS: | 7,817 lbs |
| TIRE DIMENSIONS - Tire size, front: | 10.5 |
| WEIGHTS - Wheel load per tire, rear: | 1,028 lbs |
| DIESEL ENGINE - Power SAE J1995, kW: | 37.4 kW |
| TRAVEL DRIVE - Gradeability: | 40 % |
| DIESEL ENGINE - Power SAE J1995, HP: | 50.1 hp |
| MACHINE DIMENSIONS - Ground clearance, center: | 12 in |
| TIRE DIMENSIONS - Width over tires, rear: | 50.2 in |
| BASIC DATA - Exhaust emissions category: | EU Stage V / EPA Tier 4 |
| TANK CAPACITY/FILLING CAPACITY - Fuel tank, capacity: | 19.3 gal |
| DIESEL ENGINE - Exhaust emission standard: | EU Stage V / EPA Tier 4 |
| WATER-SPRINKLING SYSTEM - Water sprinkling, type: | Pressure |
| BASIC DATA - Series: | H264 |
| MACHINE DIMENSIONS - Turning radius, inside: | 102.4 in |
| STEERING - Oscillation angle +/-: | 8 ° |
| BASIC DATA - Name: | HD 14i TT |
| TRAVEL DRIVE - Speed, infinitely variable: | 0,0-6,2 |
| SOUND LEVEL - Sound power level L(WA), guaranteed: | 101 |
| TANK CAPACITY/FILLING CAPACITY - Additive tank, capacity: | 4.8 gal |
| STEERING - Steering, type: | Articulated steering |
| BASIC DATA - Description: | Tandem roller with two sets of wheels |
| WEIGHTS - Axle load, rear: | 4,112 lbs |
| MACHINE DIMENSIONS - Maximum working width: | 50.2 in |
| WEIGHTS - Wheel load per tire, front: | 1,235 lbs |
| DIESEL ENGINE - Power SAE J1995, rpm: | 2,700 rpm |
| MACHINE DIMENSIONS - Total length: | 116.7 in |
| WEIGHTS - Empty weight without cab, without ROPS: | 7,067 lbs |
| WEIGHTS - Axle load, front: | 3,704 lbs |
| SOUND LEVEL - Acoustic power LW(A), measured: | 100 db(A) |
| DIESEL ENGINE - Power ISO 14396, HP: | 50 HP |
| MACHINE DIMENSIONS - Total height with cab: | 107.1 in |
| DIESEL ENGINE - Model: | V2403-CR-E5B |
| TIRE DIMENSIONS - Number of tires, rear: | 4 |
| TANK CAPACITY/FILLING CAPACITY - Water tank, capacity: | 68.7 gal |
| MACHINE DIMENSIONS - Total width: | 51 in |
| TIRE DIMENSIONS - Tire size, rear: | 80-16 |
| MACHINE DIMENSIONS - Center distance: | 76.8 in |
