Hamm HD 12e VV
Find Out More
-
Electrical operation, with no compromise on driving or compacting performance
-
Simple, intuitive and language-neutral control
-
Recuperation for extended lifetime
-
High efficiency from electric motors for vibration/oscillation
-
Zero local emissions, with low noise
Three-point articulation
Three-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort.
Electric rollers
Demand for low-emission or even zero-emission construction machines keeps growing. And the road construction and earthworks sector is no exception to this trend. HAMM has factored this into its product development, enabling customers around the world to benefit from quiet and emission-free compaction with electric rollers.
| WEIGHTS - Axle load, front: | 3,036 lbs |
|---|---|
| DRUM DIMENSIONS - Drum diameter, rear: | 28.3 in |
| BASIC DATA - Description: | Tandem roller with two vibrating roller drums |
| WEIGHTS - Operating weight with ROPS: | 6,075 lbs |
| MACHINE DIMENSIONS - Ground clearance, center: | 11 in |
| VIBRATION - Centrifugal force, rear, II: | 5,625 lbs |
| DRUM DIMENSIONS - Track offset, right: | 2 in |
| WEIGHTS - Static linear load, rear: | 65.1 |
| VIBRATION - Amplitude, front, I: | 0.02 in |
| WEIGHTS - Empty weight without cab, without ROPS: | 5,579 lbs |
| TRAVEL DRIVE - Climbing ability, without vibration: | 41 % |
| VIBRATION - Vibration frequency, rear, II: | 3,060 VPM |
| DRUM DIMENSIONS - Drum width, rear: | 47.2 in |
| VIBRATION - Vibration frequency, rear, I: | 3,900 VPM |
| MACHINE DIMENSIONS - Center distance: | 66.9 in |
| WEIGHTS - Static linear load, front: | 64.2 lbs/in |
| BASIC DATA - Series: | HD CompactLine |
| VIBRATION - Centrifugal force, front, I: | 9,158 lbs |
| TRAVEL DRIVE - Speed, infinitely variable: | 0,0 - 6,2 |
| BATTERY - Battery, type: | NMC lithium-ion |
| VIBRATION - Centrifugal force, front, II: | 5,625 lbs |
| VIBRATION - Centrifugal force, rear, I: | 9,158 lbs |
| VIBRATION - Vibration frequency, front, I: | 3,900 VPM |
| MACHINE DIMENSIONS - Total length: | 99.6 in |
| DRUM DIMENSIONS - Track offset, left: | 0 in |
| WEIGHTS - Axle load, rear: | 3,074 lbs |
| WATER-SPRINKLING SYSTEM - Water sprinkling, type: | Pressure |
| MACHINE DIMENSIONS - Total height with ROPS: | 97.4 in |
| BASIC DATA - Name: | HD 12e VV |
| DRUM DIMENSIONS - Drum thickness, rear: | 0.6 in |
| VIBRATION - Amplitude, rear, II: | 0.02 in |
| STEERING - Steering, type: | Articulated steering |
| DRUM DIMENSIONS - Drum type, rear: | Smooth/non-split |
| DRUM DIMENSIONS - Drum thickness, front: | 0.6 in |
| BATTERY - 230 V/400 V plug type: | CEE 7/4 (earthed type F); CEE 16 A |
| DRUM DIMENSIONS - Drum diameter, front: | 28.3 in |
| VIBRATION - Vibration frequency, front, II: | 3,060 VPM |
| MACHINE DIMENSIONS - Maximum working width: | 49.2 in |
| VIBRATION - Amplitude, front, II: | 0.02 in |
| SOUND LEVEL - Sound power level L(WA), guaranteed: | 104 |
| DRUM DIMENSIONS - Drum type, front: | Smooth/non-split |
| TANK CAPACITY/FILLING CAPACITY - Water tank, capacity: | 47.6 gal |
| VIBRATION - Amplitude, rear, I: | 0.02 in |
| MACHINE DIMENSIONS - Turning radius, inside: | 93.3 in |
| MACHINE DIMENSIONS - Total width: | 51.6 in |
| BATTERY - Capacity: | 23.4 kWh |
| DRUM DIMENSIONS - Drum width, front: | 47.2 in |
| BATTERY - Nominal voltage: | 48 V |
