Eager Beaver 60GLB-4
EAGER BEAVER – 60GLB-4 — OILFIELD LOWBOY TRAILERS®
60 Ton Fixed Gooseneck Lowboy
FEATURES
• All-Wheel ABS (6S4M) With Spring Brakes On All Axles
• 24″ Deep I-Beam Mainframe, 16″ Deep I-Beam Siderails
• 10″ Deep Crossmembers Pierced Through Mainframe
• (4) 25,000 # Axles, 5″ Diameter (3/4″ Wall), Maximum Track Width
• 275 / 70R 22.5 Radial Tires On Hub-Piloted Disc Wheels
• Cush Air Ride Suspension – 100,000 # Capacity With Lift 4th Axle
OPTIONS
• Air Lift Deck Rollers – one set 2’ Forward of Suspension, one set 6’ aft of Gooseneck
• Four Inch Dia. stanchion pockets (81” between) – one set 4’ aft of Gooseneck, one set on forward Bolster, includes stanchion pipes and stanchion pipe rack on Gooseneck
• Lockable Toolbox in Gooseneck and Expanded Metal Floor in Gooseneck
• Additional Gooseneck Lengths and Heights
• Dual Air & Electrical Connections – Front of GN and Front of Bed
• Inverted 5th Wheel
• Heavy Duty Drop Leg Supports
• Manual Raise and Lower Valve
• Oak Deck in lieu of Apitong
• Aluminum Wheels
• Spare Tire Carrier with or without Mounted Spare
• Tire & Disc Wheel 275/70R22.5 (H) Upgrade (Yokohama)
• Paint (other than standard Black, Yellow, Blue) Price on Request
OUR COMPANY…
Since 1946, Eager Beaver Trailers® has been manufacturing the highest quality construction equipment trailers from 5-100 ton capacities. The company’s approach to transportation safety has made Eager Beaver Trailers® a leader in product development and dealer support nationwide.
At Eager Beaver Trailers®, your business is important to us. As part of our customer service, we can supply you with the engineering and sales support needed for a custom-designed trailer that is best for your business.
Although many look-a-likes are on the road today, no other trailer company provides the latest technology innovations and offers more standard features on tagalongs and detachable lowboys than Eager Beaver Trailers®. We use only the highest quality components on the market to ensure a safer haul, and most importantly, a more reliable trailer.
Eager Beaver Trailers® now has a network of over 300 dealerships throughout the United States, Canada, Mexico and Latin America ready to serve your trailer needs.
Similar models may be shown in addition to the featured model. Equipment may be shown with options.
Specifications are subject to change without prior notice.
Technical Data
| Colors | Black, Yellow, Blue (standard) Imron Paint |
|---|---|
| Winch Loop | Winch Loop on Front of Gooseneck with Full Width Integrated Skid Pipe |
| Tie Down | 8- Roto Rings Per Side; Fixed D-Rings on Rear of Neck and Tailboard |
| Trailer Weight | 23,700 lbs. |
| Capacity | 120,000 lbs. |
| Deck Width | 8 ft. 6 in. |
| Weevil Pockets | Mounted every 6 ft on Outside of Side Rail and on one Bolster |
| Fairlead Roller | Fairlead Roller in Rear of Gooseneck with Weevil Pockets |
| GVWR | 126,000 lbs. |
| Crossmembers | 10” x 12 lbs. per ft. I-Beam, pierced through mainbeam (18” spacing) |
| Wiring Harness | Sealed LED Lights & USA Star PLUS Sealed Modular Wiring Harness |
| Decking | 2” Nominal Apitong wood ahead of wheels, 3/8” smooth steel over wheels |
| Height | 43 in. (Loaded) |
| Length | 56 ft. 10 in. (with 110” swing neck) |
| Frame | Mainrails: fabricated 24” Deep I-Beam. Siderails: fabricated 16” Deep I-Beam |
| Gooseneck | 4” Relief Style and 102” Swing Clearance STD (Other Lengths Available) |
| Tail Roller | Bolt on Tail Roller with Weevil Pockets and two support rollers |
Running Gear
| Axles | Four 5” Diameter 25,000 lbs. each, H.M. series bearings |
|---|---|
| Suspension | Air Ride (Combined Capacity 100,000 lbs) with Dump Valve; Lift 1st Axle |
| Brakes | 16 ½” x 7” Air, “S” Cam, Automatic Slack Adjusters |
| Tires | Sixteen 255/70R22.5 (H) Steel Belted Radial |
| Hubs/Wheels | Disc Type Hubs, 8.25 x 22.5 Disc Type Wheels, Stemco Oil Seals, Hub Piloted |
| ALL WHEEL ABS | Anti-lock brake system 4S3M, Sensors on (2) Axles, 3 modulator valves |
| Parking Brake | Spring Brakes on All Wheels |
